I. Key Features & Highlights
Engineered for High-Precision Advertising Lettering & Desktop Sign Making
The YH6090 CNC Router combines industrial-grade structural rigidity with a space-saving footprint, making it the premier choice for sign studios, boutique advertising workshops, and craft artisans. Built with an all-steel welded frame and an aluminum T-slot table, it delivers exceptional stability without desktop vibration.
- All-Axis TBI Ball Screw Drive: Unlike traditional belt or rack systems on small machines, XYZ axes are driven by precision TBI ball screws, achieving a positioning accuracy of 0.02 mm for razor-sharp micro-lettering and delicate 3D reliefs.
- Smooth Water-Cooled Spindle: Equipped with a 1.5KW high-speed water-cooled spindle (24,000 RPM) powered by a Fuling inverter, ensuring low-noise operation, minimal thermal expansion, and glass-smooth edge finishes on acrylic.
- Standard Industrial Guideways: Genuine HIWIN linear guideways provide rigid motion support and long-term positioning repeatability (0.05 mm).
- Turnkey Production Ready: Comes complete with an SL oil mist lubrication pump, automatic tool sensor, water pump, and comprehensive starter tooling kits.
II. Technical Parameters
| Feature | Specification |
| Type | Advertise CNC Router |
| Brand | YIHAICNC |
| Model | YH6090 |
| Number of axes | 3 (Optional rotary axis Customizable) |
| Number of Spindles | Single |
| Total power | 1.5KW (Customizable) |
| X,Y,Z,Working Area | 600*900*120mm(Customizable) |
| Table size | 1100*1200mm(Customizable) |
| Precision (mm) | 0.05 |
| Positioning accuracy(mm) | 0.02 |
| Frame | Steel structure lathe bed, aluminum T-slot table |
| Repeatability | 0.05mm |
| Travel speed | 20m/min |
| Processing speed | 12m/min |
| Spindle Power | 1.5KW/2.2KW/3.0KW water cooling spindle |
| Spindle Speed | 0-24000rpm |
| Transmission | TBI Ball Screw |
| Control system | NCSTUDIO / RichAuto / DSP hand controller |
| Computer Interface | USB/Ethernet |
| Working Voltage | AC 220V 50HZ |
| Command Language | G Code |
| X,Y Resolution | ＜0.03mm |
| Running Environment Temperature | 0-45 Centigrade |
| Relative Humidity | 30%-75% |
| Packing Size | 1.2*1.3*1.8M |
| Net Weight | 500KG |
| Lubrication System | Manual oil pump |
| Tool Sensor | Included |
| Inverter | FULING |
III. Machine Components Overview
Robust Construction & Certified Core Components
Designed with heavy-duty steel tube bed construction, the YH6090 integrates industrial-grade components including high-precision TBI ground ball screws, high-rigidity HIWIN linear guide rails, a durable aluminum T-slot clamping bed, and a centralized electrical control system. Every mechanical and electronic module is strictly aligned to CE standards to guarantee operator safety and consistent 24/7 machining accuracy.
YH6090 CNC advertising router: Single spindle
YH6090 CNC advertising router: Aluminum T-slot table
YH6090 CNC advertising router: Manual oil pump
YH6090 CNC advertising router: Tool setting gauge
YH6090 CNC advertising router: Control cabinet with Fuling VFD
YH6090 CNC advertising router: NcStudio control system
YH6090 CNC advertising router: Complimentary tool kit
YH6090 CNC advertising router: Processing advertising signage
IV. Applications & Processed Materials
Precision Solutions for Signage, Retail Displays & Custom Craftwork
With its dedicated 600×900mm working envelope and micro-precision motion, the YH6090 is optimized for boutique signmakers, prototyping studios, and gift manufacturers:
- Acrylic Letters & Showcase Displays: High-speed milling and polished edge cutting for 3D crystal letters, desktop POP display cases, LED illuminated signs, and high-gloss acrylic boxes.
- Personalized Wooden Crafts & Gifts: Delicate 2D/3D carving and relief engraving on wooden coasters, branded cutting boards, desktop nameplates, keepsake jewelry boxes, and intricate wooden puzzle sets.
- Industrial Plaques & Identification Badges: Precise milling and routing on brushed aluminum plaques, brass identification plates, two-color ABS engraved tags, and PVC signage boards.
V. Frequently Asked Questions
Q1: What materials can the compact YH6090 CNC router process?
A: The machine excels at machining acrylic, PVC foam board, ABS double-color sheets, solid wood, MDF, plywood, aluminum composite panels (ACP), as well as light engraving on non-ferrous metals like copper and aluminum.
Q2: Does the ball screw transmission on all three axes affect working speed?
A: Ball screw drives are purposely chosen for the YH6090 to prioritize sub-millimeter precision, edge smoothness, and fine detail over high traverse speeds. It delivers an optimal processing speed of up to 12 m/min, making it ideal for fine sign lettering and detailed reliefs.
Q3: Can I upgrade the spindle power or add a rotary axis later?
A: Yes. Spindle upgrades (2.2KW or 3.0KW) are available upon request, and the machine structure allows an optional 4th rotary axis for carving cylindrical items such as table legs, pens, and round wooden crafts.
Q4: What is the delivery lead time for this machine?
A: Delivery lead times depend on multiple variables, including custom voltage configurations, optional tooling requirements, real-time factory assembly queues, rigorous multi-point inspection routines, and shipping destinations. Our sales engineers will provide you with an exact production and shipping schedule upon confirming your order specifications.
Marek Horvat 🇭🇷 (Rijeka, Croatia) –
Hello, does the DSP controller on this 6090 machine read files directly from Mac OS via USB, or do I have to use a Windows PC to generate the toolpaths? Also interested in knowing if you include the collets for 1/8 and 1/4 shank bits.
Alex_Zhang –
Hi Marek, thank you for your inquiry! The handheld DSP controller is completely independent—it reads standard .nc or .gcode files from any FAT32-formatted USB flash drive, regardless of whether you generated them on a Mac or PC (e.g. using Fusion 360 or Vectric). And yes, we include ER20 collets (both 3.175mm/ 1/8″ and 6mm/ 1/4″) in the toolbox standard. Let us know if you need our shipping quotation to Rijeka port!
Michael Chen 🇨🇦 (Toronto, Canada) –
I’m considering the YH6090 with the aluminum T-slot table for my custom furniture business. I mainly work with hardwoods like oak and walnut for small decorative pieces. How does the T-slot clamping system perform with irregular-shaped workpieces? And what’s the positioning accuracy you’re guaranteeing for detailed inlay work?
Alex_Zhang –
Hi Michael, the aluminum T-slot table is actually ideal for irregular-shaped workpieces—you can use a combination of clamps, fixture plates, and even double-sided tape for odd shapes. The TBI ball screw drive system delivers 0.02mm positioning accuracy and 0.05mm repeatability, which is more than sufficient for fine inlay work on hardwoods. Many of our customers use the YH6090 for premium furniture detailing. We also include a starter tooling kit with collets for both 1/8″ and 1/4″ shank bits. Let us know if you need a shipping quote to Toronto!
