Description

I. Features of the CO2 Laser Engraving Machine

• Equipped with a professional dual-head system designed for simultaneous processing, effectively doubling your production capacity on a single industrial frame.

• Features a high-end dual-water and dual-gas circuit configuration, ensuring that each laser head receives independent cooling and air assist for maximum stability.

• Integrated with the authentic Ruida RDC6442S control system, utilizing a multi-button professional panel for rapid parameter adjustment and file management.

• Utilizes a standard dual-probe Auto-Focus system, allowing for instant and precise Z-axis calibration on both heads to ensure the sharpest engraving results.

• The motion architecture is built with genuine Taiwan HIWIN linear square rails and reinforced belt drives, ensuring mechanical rigidity and 0.05mm positioning accuracy.

• Incorporates an industrial-grade Honeycomb Worktable, providing superior support for small parts and efficient smoke extraction from the bottom of the material.

• Includes a built-in industrial hour meter (timer) to track cumulative working time, facilitating accurate maintenance schedules and laser tube lifespan monitoring.

• Powered by a high-capacity CO2 laser source optimized for deep cutting and fine etching on a wide variety of dense organic and polymer substrates.

• The transmission system is engineered with high-torque stepper motors, providing the driving force needed for rapid axis movement without mechanical vibration.

• Features a centralized interface connection panel on the chassis for a quick “Plug-and-Play” setup with the included exhaust blower and air assistance pumps.

• The heavy-duty reinforced chassis is designed to withstand the rigors of a 24/7 manufacturing environment, maintaining structural alignment over years of use.

• Supports a comprehensive range of industrial file formats including PLT, DXF, BMP, JPG, and AI, compatible with the most popular design software suites.

---

II. Advantages of the CO2 Laser Engraving Machine

• The primary advantage of this CO2 Laser Engraving Machine is its industrial-grade efficiency, allowing workshops to fulfill bulk orders in half the traditional time.

• By utilizing a separated dual-path cooling and gas design, the machine ensures that each laser tube remains at an optimal temperature, preventing power fluctuations.

• The Ruida RDC6442S controller offers a robust DSP logic that supports offline operation via USB or LAN, ensuring that your production is never tethered to a single PC.

• The integration of HIWIN square rails provides a significant advantage in durability, avoiding the precision loss and “wobble” often found in budget round-rail models.

• A standard auto-focus function saves significant labor time during setup, ensuring that both laser heads are always at the pinpoint focal distance for professional clarity.

• The inclusion of a digital hour meter provides a data-driven approach to maintenance, helping to extend the operational life of the expensive laser tubes and optics.

• This model acts as an exceptionally reliable CO2 Laser Cutting Machine for non-metals, producing flame-polished edges on acrylic that require no secondary sanding.

• The honeycomb table prevents thermal reflection back into the material, which is vital for maintaining a clean surface on the back of delicate laser projects.

• YIHAICNC provides a comprehensive “All-in-One” accessory package, ensuring that customers receive all necessary cooling and smoke extraction tools in one shipment.

• The asynchronous-capable motor logic allows for smart nesting strategies, which significantly reduces material waste and increases the total yield per sheet.

• Designed for 2026 industrial standards, the machine is engineered for energy efficiency relative to its processing power, reducing the total operational costs.

• The professional color-coded internal wiring and modular electrical cabinet design make it incredibly easy for technicians to perform routine maintenance or updates.

---

III. Technical Parameters

Feature	Specification
Type	CO2 Laser Engraving Machine
Brand	YIHAICNC(YIHAI CNC)
Model	YH1390(Dual-Head (Double Laser) System)
Laser source	Glass cavity sealed CO2 laser with a wavelength of 10.6μm
Laser Brand	SLW/YL/EFR/RECI/OtherBrand
Laser Power	120W(Customizable)
Total Power	＜2.5KW
Working Table	Honeycomb Worktable
Working Area	1300*900mm(Customizable)
Min Line Width	≤0.15mm
Positon Accuracy	0.05mm
Repetition Accuracy	0.02mm
Driving System	Stepper Motor
Guide Rail	Hiwin Square Rails
Transmission Method	Belt Transmission
Control System	Ruida RDC6442S(Customizable)
Operating Voltage	220v 50HZ-60HZ
Working Environment	Temperature 0-45°C Humidity 5%-95% (no condensation)
Graphic format support	PLT, DXF, BMP, JPG, AI
Option	Rotary Device Up-down Worktable Auto Focus CCD Camera Honeycomb Table Servo Motor

---

IV. Key Components Description

	Honeycomb Worktable / Honeycomb Platform Function: Specifically designed for processing soft and small materials (such as fabric, paper, or small acrylic parts). It offers excellent ventilation, effectively reduces laser reflection, and prevents small workpieces from falling through during the cutting process.
Dual Laser Head Configuration (Two Standard Laser Heads + Auto-Focus) Function: Both laser heads are equipped with auto-focus modules, allowing them to perform engraving and cutting tasks asynchronously to boost processing efficiency.
	Integrated Control Cabinet (Equipped with Ruida RDC6442S System) Function: Managed by the world-renowned Ruida RDC6442S control system, supporting professional features such as asynchronous dual-head control and visual path optimization.
High-Performance, High-Precision CO2 Laser Tube Function: The core power source, delivering a stable 10.6μm beam. Designed specifically for deep cutting and fine engraving on organic substrates, it features an industrial-grade lifespan and consistent energy output.
	Centralized External Interface Panel (Dual-Channel Design) Function: Features a high-quality dual-water-circuit and dual-air-circuit design, ensuring that each laser head receives independent water cooling and air assist supplies to maintain optimal processing temperatures.
Integrated USB and LAN Data Interfaces Function: Supports high-speed data transmission and offline operation. Users can upload files via USB flash drives, USB cables, or a network connection, offering maximum flexibility and efficient file management for professional workshops.
	DSP Control Panel and Emergency Stop Button Function: Equipped with an intuitive LCD screen, allowing for real-time monitoring of current speed and power parameters. Industrial-grade mechanical buttons provide clear tactile feedback, while the emergency stop button enables instantaneous power cutoff and machine shutdown in urgent situations, thereby maximizing operator safety.
DSP Control Panel and Emergency Stop Button Function: Equipped with an intuitive LCD screen, allowing for real-time monitoring of current speed and power parameters. Industrial-grade mechanical buttons provide clear tactile feedback, while the emergency stop button enables instantaneous power cutoff and machine shutdown in urgent situations, thereby maximizing operator safety.
	Complete Standard Accessories Package Function: Includes a centrifugal exhaust fan, an electromagnetic air pump, and a water cooling assembly. This comprehensive kit ensures that your CO2 laser cutter is ready for immediate production use upon delivery.

---

V. Applicable Materials

The CO2 Laser Engraving Machine is a specialist in processing an extensive range of non-metallic substrates. It delivers outstanding results on wood, acrylic, MDF, and plywood. For the creative and textile sectors, it handles leather, fabric, felt, and paper with extreme precision. It is also suitable for etching fine details onto glass, stone, and ceramics, as well as processing rubber and various organic polymers, providing a comprehensive solution for diverse workshop needs.

---

VI. Applicable Industries and Future Prospects

The Gift and Personalization Industry stands as a primary beneficiary of this dual-head configuration. In 2026, the demand for “hyper-personalized” goods requires small businesses to handle large volumes of custom orders quickly. This CO2 Laser Engraving Machine allows entrepreneurs to process two items—such as custom wood plaques or leather wallets—simultaneously, doubling their throughput. As consumers continue to move away from mass-produced items toward unique, locally crafted goods, the efficiency provided by the YIHAICNC series ensures that small workshops remain competitive and profitable.

In the Advertising and Signage Industry, the large-format dual-head logic is essential for producing acrylic letters, illuminated signs, and directory boards. The precision of the HIWIN rails ensures that intricate fonts and logos are etched with professional clarity. By using the machine as a high-capacity CO2 Laser Cutting Machine, sign shops can cut multiple parts from a single sheet in record time. As brands invest more in physical branding and sophisticated indoor displays, the demand for reliable, large-scale laser tools is projected to see significant global growth through the end of the decade.

The Educational and STEM Sector is increasingly adopting these robust machines for digital fabrication. Schools and community maker spaces need equipment that is both safe and feature-rich to teach students the principles of CAD/CAM manufacturing. The YH1390’s Ruida system and independent circuits make it an ideal educational tool, allowing multiple students to observe different processing tasks on one frame. Future prospects in this sector include the integration of laser technology into architectural modeling and sustainable design courses, ensuring a steady demand for high-quality workshop equipment.

Looking toward the future, the Smart Manufacturing and Local Prototyping movement is driving the need for more automated workshop tools. Small-to-medium enterprises (SMEs) are moving toward on-demand production models to reduce inventory costs. The YIHAICNC series is positioned as the backbone of these modern “micro-factories.” The prospects for this technology are tied to the global shift toward sustainable, locally produced goods that require the precision, efficiency, and material versatility of a professional CO2 laser system.

---

VII. Safety Precautions and Guidelines

• Eye Protection: Always wear certified 10.6μm wavelength protective goggles to prevent permanent eye damage from invisible laser reflections.

• Fire Safety: Never leave the machine unattended while cutting. Materials like wood and acrylic are flammable; always keep a fire extinguisher nearby.

• Ventilation: Ensure the centrifugal exhaust blower is correctly vented to an outdoor area. Burning plastics and MDF can release harmful smoke and VOCs.

• Cooling Verification: Always check that the water chiller is turned on and water is flowing through the tube before firing the laser to prevent the glass from cracking.

• Dual Head Clearance: When running asynchronous jobs, ensure the two laser heads have sufficient clearance to prevent collision during high-speed motion.

---

VIII. Frequently Asked Questions (FAQ)

Q1: How does the “Dual Water and Dual Gas Circuit” system benefit my business?

The dual-circuit configuration on the CO2 Laser Engraving Machine is a hallmark of industrial-grade engineering. In standard dual-head machines, sharing a single cooling line can lead to the second laser tube running hotter than the first, which causes its power to drop and shortens its lifespan. YIHAICNC’s separated dual-path system ensures that each laser tube receives its own dedicated cooling loop from the chiller and its own independent air assist pressure. This redundancy ensures that the laser power remains perfectly consistent on both heads, even during long, 10-hour production shifts. For a professional workshop, this means identical cut quality on every part of the sheet, reducing material waste and ensuring that your production remains stable under heavy workloads.

Q2: What is the specific role of the Ruida RDC6442S in a dual-head configuration?

The Ruida RDC6442S utilized in this machine is a professional DSP controller designed specifically for multi-axis motion management. Its primary role in a CO2 Laser Engraving Machine with two heads is to handle the complex logic of “Dual Head Control.” Through the multi-button panel, the operator can easily toggle between single-head and dual-head modes, adjust the power offset between the two tubes, and manage asynchronous paths. The controller’s robust internal memory allows it to process large vector files with thousands of nodes without lag, ensuring that the motion remains fluid and the positioning accuracy stays at 0.05mm. This professional-grade control is what allows YIHAICNC machines to transition seamlessly from delicate engraving to heavy-duty industrial cutting.

Q3: Why is the inclusion of an industrial timer (hour meter) important for maintenance?

In the industrial world, data is the key to longevity. The industrial hour meter on this CO2 Laser Engraving Machine acts as an odometer for your equipment. Laser tubes and optics have specific maintenance cycles; for example, mirrors should be checked every 50 hours, and laser tubes often have a rated life of 10,000 hours. By having a clear, digital record of cumulative working hours, the workshop manager can schedule preventive maintenance—like rail lubrication or water replacement—before a failure occurs. This proactive approach prevents unexpected downtime and ensures that the machine is always operating at its peak efficiency. It also provides an objective record of machine usage, which is a valuable asset if the machine is ever resold or audited for industrial compliance.

Q4: Can this machine be used as a CO2 Laser Cutting Machine for thick materials?

Absolutely. While the dual-head system is optimized for batch efficiency, the high-power CO2 laser source ensures it is a very capable CO2 Laser Cutting Machine. Depending on the wattage of the tubes installed (e.g., 100W or 130W), this machine can slice through 15mm or even 20mm clear acrylic in a single pass. The high-quality optics and stable HIWIN linear square rails ensure that the cut edge remains vertical and clean. For acrylic, the result is often a flame-polished edge that requires no secondary finishing. This versatility is essential for the 1390 format, as it allows the operator to switch from high-volume custom engraving on leather to heavy-duty architectural signage production on the same platform, maximizing the workshop’s return on investment.

Q5: What maintenance is required to maintain the 0.05mm positioning accuracy?

Maintenance for a professional CO2 Laser Engraving Machine is straightforward but essential for industrial precision. Daily, the operator should clean the three reflective mirrors and the focal lenses of both heads using high-purity isopropyl alcohol to prevent smoke residue from burning into the coatings. Weekly, the Taiwan HIWIN linear rails should be wiped clean and a light coat of rail lubricant applied to ensure smooth movement across the 1300mm span. Additionally, the water in your industrial chiller should be replaced with distilled water every 2 months to prevent mineral buildup inside the laser tubes. Following these simple steps ensures that your YIHAICNC machine maintains its high repetition accuracy and industrial power output for several years of heavy workshop use.

Q6: Is the machine compatible with popular software like LightBurn and RDWorks?

Yes, the Ruida controller makes this machine one of the most compatible on the market. It comes with the free RDWorks V8 software, which includes specialized plugins for AutoCAD, CorelDraw, and Adobe Illustrator, allowing you to design in your preferred environment and send jobs directly to the machine. It is also fully compatible with LightBurn, which is the global favorite for its intuitive interface, advanced nesting features, and powerful path optimization. This software compatibility ensures that your existing design workflow is not only preserved but significantly enhanced by the professional capabilities of the YH1390. You can transfer files via USB, Ethernet, or even a U-disk for completely offline operation, providing maximum flexibility for your production environment.
