Description

I. Features of the YH1390 CO2 Laser Engraving Machine

• Equipped with a specialized 1300mm x 900mm (1390) working area, optimized for standard-sized stone slabs, monuments, and decorative tiles.

• Features a unique open-chassis hydraulic lifting platform, specifically designed to handle the extreme weight of heavy stone and marble materials.

• Utilizes a heavy-duty weighted industrial frame, providing the mass required to absorb vibrations during high-speed engraving on dense stone surfaces.

• Powered by the authentic Ruida RDC6442S control system, offering industrial-grade DSP logic and stable offline operation via USB or network connection.

• The motion system is built with genuine Taiwan HIWIN linear square rails on both X and Y axes, ensuring mechanical rigidity and long-term accuracy.

• Incorporates a high-precision integrated auto-focus probe, allowing for rapid and consistent Z-axis calibration on uneven or varying stone thicknesses.

• Transmission is executed via high-tenacity industrial belt drives, providing smooth movement and reducing mechanical noise compared to gear systems.

• Includes a standard single laser head configuration optimized for the 10.6μm wavelength, ideal for high-contrast etching on organic and stone substrates.

• The hydraulic height adjustment system allows for a flexible vertical range, accommodating bulky objects and irregular tombstone shapes with ease.

• Integrated with a professional air assist system using an electromagnetic air pump to clear dust and protect the focus lens during heavy stone processing.

• Supports a wide variety of industrial file formats, including PLT, DXF, BMP, JPG, and AI, compatible with mainstream CAD and graphic design software.

• The standard shipping package is a comprehensive “Plug-and-Play” kit, featuring a centrifugal exhaust blower and industrial water cooling systems.

---

II. Advantages of the YH1390 Laser System

• The primary advantage of this CO2 Laser Engraving Machine is its heavy-duty hydraulic capability, allowing one operator to process stones that are too heavy for standard machines.

• By utilizing a weighted chassis, the machine maintains a positioning accuracy of 0.05mm even when the laser head moves at high speeds over hard stone surfaces.

• The open-chassis design provides a vital logistical advantage, allowing for the use of pallet jacks or forklifts to position heavy stone slabs directly onto the lift.

• YIHAICNC’s integration of HIWIN square rails ensures that the mechanical precision remains consistent over years of use, preventing the “wobble” found in round-rail machines.

• The hydraulic system provides much more power and durability than traditional lead-screw lifts, making it the choice for 24/7 industrial monument manufacturing.

• This system doubles as an effective CO2 Laser Cutting Machine for non-metallic templates, allowing users to cut acrylic or wood stencils for sandblasting projects.

• The Ruida RDC6442S controller is internationally recognized for its ease of use and compatibility with advanced photo-engraving software like LightBurn and RDWorks.

• Our specialized air assist technology prevents the buildup of stone dust on the optics, extending the operational life of the mirrors and the expensive focal lens.

• The 1390 format is the “Sweet Spot” for the masonry industry, fitting most headstones and decorative panels while maintaining a compact workshop footprint.

• YIHAICNC provides a cost-effective solution for stone masons who need professional-grade results without the high investment cost of fiber marking systems.

• The asynchronous motor logic allows for fine-tuning the engraving depth, which is essential for creating high-contrast photos and text on dark granite or marble.

• Designed for the 2026 global market, the YH1390 is engineered for long-term industrial uptime with minimal mechanical maintenance required for the lift system.

---

III. Technical Parameters

Feature	Specification
Type	CO2 Laser Engraving Machine
Brand	YIHAICNC(YIHAI CNC)
Model	YH1390(Heavy-Duty Stone Processing + Hydraulic Lift Platform)
Laser source	Glass cavity sealed CO2 laser with a wavelength of 10.6μm
Laser Brand	SLW/YL/EFR/RECI/OtherBrand
Laser Power	300W(Customizable)
Total Power	＜3KW
Working Table	Open-Chassis Hydraulic Lifting Platform
Working Area	1300*900mm(Customizable)
Min Line Width	≤0.15mm
Positon Accuracy	0.05mm
Repetition Accuracy	0.02mm
Driving System	Stepper Motor
Guide Rail	Hiwin Square Rails
Transmission Method	Belt Transmission
Control System	Ruida RDC6442S(Customizable)
Operating Voltage	220v 50HZ-60HZ
Working Environment	Temperature 0-45°C Humidity 5%-95% (no condensation)
Graphic format support	PLT, DXF, BMP, JPG, AI
Option	Rotary Device Up-down Worktable Auto Focus CCD Camera Honeycomb Table Servo Motor

---

IV. Key Components Description

	Open-Chassis Hydraulic Lifting Platform Features a unique open-chassis hydraulic lifting platform, specifically engineered to handle the immense weight of heavy stone and marble materials.
Close-up views of the Open-Chassis Hydraulic Lifting Platform from various angles
	Close-up views of the Open-Chassis Hydraulic Lifting Platform from various angles
High-Performance, High-Precision CO2 Laser Tube Function: The core power source, delivering a stable 10.6μm beam. Designed specifically for deep cutting and fine engraving on organic substrates, it features an industrial-grade lifespan and consistent energy output.
	Integrated USB and LAN Data Interfaces Function: Supports high-speed data transmission and offline operation. Users can upload files via USB flash drives, USB cables, or a network connection, offering maximum flexibility and efficient file management for professional workshops.
Integrated Control Cabinet (Equipped with Ruida RDC6442S System) Function: Managed by the world-renowned Ruida RDC6442S control system, supporting professional features such as asynchronous dual-head control and visual path optimization.
	Centralized External Interface Panel Function: Simplifies the equipment installation process; each interface is clearly labeled, covering water inlet/outlet ports, air assist ports, and power outlets. This “plug-and-play” design philosophy allows you to quickly connect the water chiller and air compressor without the hassle of complex wiring.
DSP Control Panel and Emergency Stop Button Function: Equipped with an intuitive LCD screen, allowing for real-time monitoring of current speed and power parameters. Industrial-grade mechanical buttons provide clear tactile feedback, while the emergency stop button enables instantaneous power cutoff and machine shutdown in urgent situations, thereby maximizing operator safety.
	Complete Standard Accessories Package Function: Includes a centrifugal exhaust fan, an electromagnetic air pump, and a water cooling assembly. This comprehensive kit ensures that your CO2 laser cutter is ready for immediate production use upon delivery.

---
