Description

I. Features of the CO2 Laser Engraving Machine

• Features a massive 1300mm x 2500mm (YH1325) working area, providing a professional solution for large-format sheet processing without the need for pre-cutting materials.

• Equipped with an industrial-grade SLW 300W CO2 laser source, delivering a concentrated 10.6μm beam for high-speed engraving and deep penetration on thick organic materials.

• The machine bed undergoes a professional heavy-duty weighting and annealing process, eliminating internal stress to ensure structural stability and a long operational lifespan.

• Utilizes genuine Taiwan HIWIN linear square rails combined with reinforced belt drives, ensuring mechanical rigidity and 0.05mm positioning accuracy across the large bed.

• Includes a redesigned, optimized smoke extraction flue system, engineered to effectively remove dust and fumes even during intensive large-scale processing sessions.

• Features a specialized Blade Worktable (slat bed) optimized for flexible materials like leather and fabric, reducing heat accumulation and laser back-reflection.

• Incorporates a humanized waste collection drawer at the base, allowing operators to easily clean up scrap materials and maintain a tidy and professional workspace.

• Managed by the authentic Ruida RDC6442S control system, offering industrial DSP logic for stable motion control and reliable offline operation via USB or LAN.

• The transmission architecture is driven by high-torque stepper motors, providing the necessary force to move the large-format X-axis bridge with precision and speed.

• Integrated with a professional air assist system and a red-light positioning pointer to improve cutting efficiency and assist in rapid material alignment on the bed.

• The chassis is finished with a premium industrial dark blue and white protective coating, designed to withstand the rigors of a continuous manufacturing environment.

• Standard shipping package is a comprehensive “Ready-to-Work” kit, featuring a high-volume centrifugal exhaust blower and industrial water cooling systems.

---

II. Advantages of the CO2 Laser Engraving Machine

• The primary advantage of the YH1325 CO2 Laser Engraving Machine is its large-format capacity, allowing sign makers to process full 4×8 foot sheets in a single cycle.

• By utilizing the SLW 300W laser tube, this machine provides a significant efficiency boost, completing deep cutting tasks much faster than standard lower-wattage models.

• The annealed and weighted frame is a vital structural advantage, as it prevents the vibration and “ghosting” that often occurs on lighter frames during rapid axis travel.

• YIHAICNC’s redesigned smoke flue ensures that even when processing large quantities of fabric or leather, the workshop remains clear of harmful smoke and odor.

• This system serves as an exceptionally powerful CO2 Laser Cutting Machine for non-metals, capable of slicing through 25mm acrylic with a professional polished edge.

• The integration of HIWIN square rails ensures that the machine retains its mechanical precision over years of use, avoiding the wear common in round-rail hobbyist units.

• The humanized drawer design simplifies the cleanup process, reducing the downtime between jobs and improving the overall productivity of the industrial workshop.

• Ruida RDC6442S compatibility with professional software like LightBurn gives users access to advanced path optimization and smart nesting for material savings.

• Our integrated air assist technology creates a protective air curtain at the nozzle, extending the life of the optics and keeping the focal lenses clear of debris.

• The 1325 format is specifically optimized for the global furniture and signage industries, fitting standard material sheets while maintaining a manageable footprint.

• YIHAICNC provides a comprehensive “All-in-One” accessory package, ensuring that the customer receives all necessary cooling and extraction tools in one shipment.

• Designed for 2026 industrial standards, the YH1325 is engineered for maximum uptime and durability, offering a sustainable solution for growing manufacturing businesses.

---

III. Technical Parameters

Feature	Specification
Type	CO2 Laser Engraving Machine
Brand	YIHAICNC(YIHAI CNC)
Model	YH1325(Standard Configuration: Single Laser Head)
Laser source	Glass cavity sealed CO2 laser with a wavelength of 10.6μm
Laser Brand	SLW/YL/EFR/RECI/OtherBrand
Laser Power	300W(Customizable)
Total Power	＜3KW
Working Table	Blade Worktable
Working Area	1300*2500mm(Customizable)
Min Line Width	≤0.15mm
Positon Accuracy	0.02mm
Repetition Accuracy	0.02mm
Driving System	Stepper Motor
Guide Rail	Hiwin Square Rails
Transmission Method	Belt Transmission
Control System	Ruida RDC6442S(Customizable)
Operating Voltage	220v 50HZ-60HZ
Working Environment	Temperature 0-45°C Humidity 5%-95% (no condensation)
Graphic format support	PLT, DXF, BMP, JPG, AI
Option	Rotary Device Up-down Worktable Auto Focus CCD Camera Honeycomb Table Servo Motor

---

IV. Key Components Description

	Professional Blade Worktable Function: Designed specifically for hard non-metal materials such as wood and acrylic. The blade structure minimizes surface contact and laser back-reflection, ensuring cleaner bottom edges for your CO2 laser cutting projects.
Integrated Control Cabinet (Equipped with Ruida RDC6442S System) Function: Managed by the world-renowned Ruida RDC6442S control system, supporting professional features such as asynchronous dual-head control and visual path optimization.
	Standard Laser Head + Auto-Focus Function: Designed specifically for the cutting and engraving of non-metallic materials. The integrated auto-focus probe ensures precise focal positioning, thereby maximizing the precision of the CO2 laser engraving machine.
SLE High-Performance, High-Precision CO2 Laser Tube Function: The core power source, delivering a stable 10.6μm beam. Designed specifically for deep cutting and fine engraving on organic substrates, it features an industrial-grade lifespan and consistent energy output.
	DSP Control Panel and Emergency Stop Button Function: Equipped with an intuitive LCD screen, allowing for real-time monitoring of current speed and power parameters. Industrial-grade mechanical buttons provide clear tactile feedback, while the emergency stop button enables instantaneous power cutoff and machine shutdown in urgent situations, thereby maximizing operator safety.
Centralized External Interface Panel Function: Simplifies the equipment installation process; each interface is clearly labeled, covering water inlet/outlet ports, air assist ports, and power outlets. This “plug-and-play” design philosophy allows you to quickly connect the water chiller and air compressor without the hassle of complex wiring.
	Waste Collection Drawer Function: Features an ergonomically designed waste collection drawer located at the bottom, allowing operators to easily clear debris and maintain a clean, professional workspace.
Complete Standard Accessories Package Function: Includes a centrifugal exhaust fan, an electromagnetic air pump, and a water cooling assembly. This comprehensive kit ensures that your CO2 laser cutter is ready for immediate production use upon delivery.

---

V. Applicable Materials

The YH1325 CO2 Laser Engraving Machine is a specialist in processing large-format non-metallic substrates. It delivers outstanding results on acrylic, wood, MDF, and plywood. For the textile and fashion sectors, it is highly effective for cutting and engraving leather, fabric, and industrial felt. Additionally, it can process glass, stone, rubber, and various organic polymers, providing a versatile solution for workshops that require a massive processing area for both rigid and flexible materials.

---

VI. Applicable Industries and Future Prospects

The Advertising and Signage Industry remains the core market for the YH1325. Sign shops require the 1300x2500mm area to produce full-sized acrylic signs, illuminated channel letters, and large wooden display boards. This CO2 Laser Engraving Machine allows them to process entire sheets at once, significantly reducing labor and material handling time. As brands invest more in physical branding and sophisticated indoor displays, the demand for reliable, large-scale laser tools is projected to see steady global growth through 2026.

In the Textile and Garment Industry, the YH1325 is used for cutting large fabric panels and engraving intricate patterns on leather hides. The specialized blade table and redesigned flue make it an ideal tool for processing soft materials that generate significant smoke. As the fashion industry moves toward “On-Demand” manufacturing, the ability to quickly produce large-scale cut pieces without expensive tooling becomes a vital competitive advantage for modern textile workshops.

The Furniture and Architectural Decoration sector utilizes the YH1325 to create custom wooden screens, fretwork panels, and bespoke acrylic furniture components. The 300W SLW tube provides the raw power needed as a CO2 Laser Cutting Machine to slice through thick decorative panels with industrial speed. As sustainable interior design trends favor natural materials like wood and bamboo with customized artisanal details, the YH1325 provides a scalable platform for interior designers to bring digital concepts to physical reality.

Looking toward the future, the Smart Manufacturing and Localized Fabrication movement is driving the need for more automated workshop tools. Small-to-medium enterprises (SMEs) are moving toward “Micro-Factory” models to reduce inventory and logistics costs. The YIHAICNC series is positioned as the backbone of these modern manufacturing hubs. The prospects for this technology are tied to the global shift toward sustainable, locally produced goods that require the precision, efficiency, and material versatility of a professional CO2 laser system.

---

VII. Safety Precautions and Guidelines

• Eye Protection: Always wear certified 10.6μm wavelength protective goggles when the laser is active to prevent permanent eye damage from invisible reflections.

• Fire Safety: Never leave the machine unattended while cutting. Materials like wood and acrylic are flammable; always keep a CO2 fire extinguisher within immediate reach.

• Ventilation: Ensure the centrifugal exhaust blower is correctly vented to an outdoor area. Burning fabrics and MDF can release harmful smoke that must be removed.

• Cooling Verification: Always check that the water chiller is turned on and water is flowing through the tube before firing the laser to prevent the glass from cracking.

• Waste Management: Regularly empty the integrated waste drawer to prevent the buildup of flammable scraps and maintain optimal air flow within the machine chassis.

---

VIII. Frequently Asked Questions (FAQ)

Q1: What are the specific benefits of the SLW 300W laser source for large-format work?

The SLW 300W laser source utilized in the CO2 Laser Engraving Machine is an industrial powerhouse designed for high-efficiency production. Its primary benefit is “Processing Speed.” When you are working on a 1300x2500mm bed, the travel distances are large; having a 300W beam allows you to cut through materials like 20mm acrylic or 15mm plywood in a single pass at much higher speeds than a 100W or 150W tube. This reduces the total time per project, allowing your workshop to handle more contracts. Furthermore, the SLW brand is known for its stable beam quality and excellent energy distribution, which is critical for maintaining a consistent cut finish across the entire 2.5-meter table length without power fluctuations.

Q2: Why does YIHAICNC perform an “Annealing Process” on the machine bed?

Annealing is a specialized heat treatment that is rarely found in entry-level machines but is a standard for YIHAICNC’s industrial models. During the welding of a large 1325 frame, internal stresses are created in the steel. If these stresses are not removed, the frame can slightly warp or twist over time, ruining the machine’s precision. By heating the entire bed in a professional furnace and cooling it slowly (annealing), we “relax” the metal, ensuring the frame remains perfectly flat and stable for its entire lifespan. This is what allows our CO2 Laser Engraving Machine to maintain a positioning accuracy of 0.05mm even after years of heavy industrial use, protecting your long-term investment.

Q3: How does the redesigned smoke flue system improve the processing of fabric and leather?

Processing soft materials like fabric and leather on a CO2 Laser Engraving Machine generates a large volume of dense, often odorous smoke. If this smoke is not removed immediately, it can settle on the material, causing yellowing or staining, and it can also cloud the laser beam, reducing cutting efficiency. YIHAICNC has redesigned the internal flue system on the YH1325 to create a more powerful and directed airflow. By optimizing the paths through which air is sucked out, we ensure that smoke is pulled away from the laser head and the material surface instantly. This keeps your fabric edges clean, protects your focal lens from residue, and ensures a healthier working environment for your workshop operators.

Q4: What is the purpose of the humanized waste drawer in the YH1325 design?

Efficiency in an industrial workshop is often found in the small details. When cutting dozens of small parts on a large 1300x2500mm bed, scrap material and “cut-outs” inevitably fall through the blade table. In many machines, these scraps are difficult to reach and can even become a fire hazard if they accumulate near the laser path. The YH1325 features an integrated, slide-out waste drawer. All small scraps are collected in this centralized area, allowing the operator to empty the machine in seconds at the end of a shift. This not only keeps the internal cabinet clean for better air flow but also significantly reduces the maintenance time required to keep the machine in top working condition.

Q5: Is the Ruida RDC6442S controller compatible with professional software like LightBurn?

Absolutely. The Ruida RDC6442S is the global industry standard for high-end CO2 Laser Engraving Machine control. It is fully compatible with LightBurn, which is the preferred software for professional operators due to its intuitive interface and advanced path optimization tools. It also comes with the free RDWorks V8 software, which includes plugins for AutoCAD, CorelDraw, and Adobe Illustrator. This software ecosystem allows you to design your large-format signage or furniture in your favorite CAD environment and send jobs directly to the machine. You can transfer files via USB cable, Ethernet for network control, or even a U-disk for completely offline operation, providing maximum flexibility for your production workflow.

Q6: What maintenance is required to maintain the industrial accuracy of the YH1325?

Maintenance for a professional CO2 Laser Engraving Machine focuses on cleanliness and lubrication. Daily, the operator should clean the three reflective mirrors and the focal lens using high-purity isopropyl alcohol to prevent smoke residue from burning into the coatings. Weekly, the Taiwan HIWIN linear rails should be wiped clean and a light coat of rail lubricant applied to ensure smooth movement across the massive 1325 span. Additionally, because a 300W tube generates more heat, the water in your industrial chiller should be replaced with distilled water every 2 months to prevent mineral buildup. Following these simple steps ensures that your YIHAICNC machine maintains its high repetition accuracy and industrial power output for several years of heavy workshop use.
